Vertical balancing machine is a device typically used to balance rotors and other rotating parts around a vertical axis. These machines are designed to mount and rotate parts vertically. Vertical balancing machines are particularly suitable for parts that are difficult to balance horizontally due to their shape and size.

Vertical balancing machines have the following components:

Sensors: Measure the imbalances and vibrations of the part. These sensors are usually placed along the vertical axis of the part.

Rotary Table: The platform on which the part is mounted and rotated vertically.

Control Unit: Analyzes data from the sensors and calculates the amount and location of the imbalance.

Correction Mechanism: Adds or removes weight from the part or performs other corrective actions to eliminate imbalances.

Display and User Interface: Allows the user to control the machine and view analysis results.

Vertical balancing machines are used in various industries, such as:

Electric Motors: Balancing rotors and armatures.

Pumps and Compressors: Balancing impellers and compressor rotors.

Fans and Turbines: Balancing industrial fans and turbines.

Aerospace: Balancing aircraft engine components and spacecraft parts.

Vertical balancing machines are especially preferred for parts that require precise balancing and operate at high speeds. These machines enhance the performance of the part, reduce vibrations, and ensure longer service life.



Balancia V-100
Maximum Rotor Weight	100 kg (220,46 lb.)
Minimum. Rotor Weight	1 kg (2,20 lb.)
Maximum Rotor Diameter	500 mm (19,69 in.)
Min Rotor Diameter	100 mm (3,94 in.)
Correction plane	1
Motor power	4 kW (5,44 HP)
Drive	4 kW (5,44 HP)
Maximum Balancing Speed	120-1500 rpm (2 -25 Hz)
Position Detection Time	8-25 sn
Machine Weight	1100 kg (2425,09 lb.)
Sensitivity (in a plane)	1 gmm (0.45 ginch)
Balancing the amount of grams and the drill depth reading	Available
Static balance representation Available	Available
Measuring Unit	Balancer V2.7
Language	English
Processor	Intel
Display	23,8” LCD
Operating System	Windows 11
